Description
XP POWER - IU1203SA - Isolated Through Hole DC/DC Converter, Regulated, ITE, 2:1, 2 W, 1 Output, 3.3 V, 500 mA
- CONVERTER, DC/DC, 2: 1I/P, 2W, 3.3V
 - No. of Outputs: 1 Output
 - Output Power Max: 2W
 - Output Voltage - Output 1: 3.3V
 - Output Current - Output 1: 500mA
 - Output Voltage - Output 2: -
 - Output Current - Output 2: -
 - Output Voltage - Output 3: -
 - Output Current - Output 3: -
 - Product Range: -
 - Input Voltage DC Min: 9V
 - Input Voltage DC Max: 18V
 - DC / DC Converter Output Type: Fixed
 - DC / DC Converter Type: SIP
 - DC / DC Converter Mounting: Through Hole
 - Width: 9.2mm
 - Height: 11.1mm
 - Depth: 21.85mm
 - SVHC: No SVHC (15-Jan-2018)
 - Efficiency: 66%
 - External Depth: 11.1mm
 - External Length / Height: 21.85mm
 - External Width: 9.2mm
 - Isolation Voltage: 1kV
 - Line Regulation: 0.5%
 - Load Regulation: 1%
 - No. of Outputs: 1Outputs
 - Off Load Current: 15mA
 - Operating Temperature Max: 85°C
 - Operating Temperature Min: -40°C
 - Output Ripple Voltage pk-pk: 80mV
 - Power Rating: 2W
 - Supply Voltage: 12V
