Description
XP POWER - ITQ2412S - Isolated Through Hole DC/DC Converter, 1.5kV Isolation, ITE, 4:1, 6 W, 2 Output, 12 V, 250 mA
- No. of Outputs: 2 Output
- Output Power Max: 6W
- Output Voltage - Output 1: 12V
- Output Current - Output 1: 250mA
- Output Voltage - Output 2: -12V
- Output Current - Output 2: 250mA
- Output Voltage - Output 3: -
- Output Current - Output 3: -
- Product Range: ITQ Series
- Input Voltage DC Min: 9V
- Input Voltage DC Max: 36V
- DC / DC Converter Output Type: Fixed
- DC / DC Converter Type: SIP
- DC / DC Converter Mounting: Through Hole
- Width: 21.85mm
- Height: 11.1mm
- Depth: 9.2mm
- SVHC: No SVHC (15-Jan-2018)
- No. of Outputs: 2Outputs
