XP POWER - IH0515S-H - Isolated Through Hole DC/DC Converter, ITE, 1:1, 2 W, 2 Output, 15 V, 66 mA
- No. of Outputs: 2 Output
 - Output Power Max: 2W
 - Output Voltage - Output 1: 15V
 - Output Current - Output 1: 66mA
 - Output Voltage - Output 2: -15V
 - Output Current - Output 2: 66mA
 - Output Voltage - Output 3: -
 - Output Current - Output 3: -
 - Product Range: IH Series
 - Input Voltage DC Min: 4.5V
 - Input Voltage DC Max: 5.5V
 - DC / DC Converter Output Type: Fixed
 - DC / DC Converter Type: SIP
 - DC / DC Converter Mounting: Through Hole
 - Width: 7.62mm
 - Height: 10.16mm
 - Depth: 19.5mm
 - SVHC: No SVHC (15-Jan-2018)
 - Efficiency: 80%
 - External Depth: 10.16mm
 - External Length / Height: 19.81mm
 - External Width: 7.62mm
 - Input Voltage: 5V
 - Isolation Voltage: 3kV
 - No. of Outputs: 2Outputs
 - Off Load Current: 30mA
 - Operating Temperature Max: 85°C
 - Operating Temperature Min: -40°C
 - Output Current - Max: 66mA
 - Output Ripple Voltage pk-pk: 60mV
 - Output Voltage +: 15V
 - Output Voltage -: 15V
 - Output Voltage Max: 15V
 - Output Voltage Min: -15V
 - Power Rating: 2W
 - Supply Voltage: 5V
