BROADCOM - HLMP-2350 - LED Bar Graph Array, Red, 20 mA, 2 V, 45 mcd, 4 LEDs, 19.05mm x 3.81mm
- LED Colour: Red
- Forward Current If: 20mA
- Forward Voltage: 2V
- Luminous Intensity: 45mcd
- No. of LEDs: 4LEDs
- Display Size: 19.05mm x 3.81mm
- Product Range: -
- SVHC: No SVHC (15-Jan-2018)
- External Depth: 6.22mm
- External Length / Height: 4.95mm
- External Width: 20.32mm
- Forward Voltage VF Max: 1.8V
- LED Configuration: Bar Module
- Lead Cross-section Depth: 0.51mm
- Lead Cross-section Width: 0.58mm
- Lead Spacing: 2.54mm
- Luminous Intensity Typ: 45mcd
- No. Segments: 1
- Operating Temperature Max: 85°C
- Operating Temperature Min: -40°C
- Operating Temperature Range: -40°C to +85°C
- PIV Max: 6V
- Peak Forward Current: 30mA
- Peak Wavelength: 635nm
- Wavelength Typ: 635nm
