Description
LEM - HAIS 50-TP - Current Transducer, HAIS Series, 50A, -150A to 150A, 1 %, Voltage Output, 4.75 Vdc to 5.25 Vdc
- Sensor Output: Voltage
- Supply Voltage DC Min: 4.75V
- Supply Voltage DC Max: 5.25V
- Current Measuring Range DC: -150A to 150A
- Current Measuring Range AC: -150A to 150A
- Response Time: 5µs
- Accuracy %: 1%
- Product Range: HAIS - P/TP Series
- SVHC: No SVHC (15-Jan-2018)
- Accuracy: 1%
- Current Consumption: 22mA
- Current Range AC: DC, AC, Pulsed, Mixed
- Current Range DC: DC, AC, Pulsed, Mixed
- Current Rating: 50A
- External Depth: 25.9mm
- External Length / Height: 29mm
- External Width: 33mm
- Flammability Rating: UL 94-V0
- Frequency Max: 50kHz
- Frequency Min: 0Hz
- Linearity: ± 0.5%
- Operating Temperature Max: 85°C
- Operating Temperature Min: -40°C
- Standard: EN 50178(97-10-01)
- Supply Voltage: +5V
- Supply Voltage Range DC: 4.75V to 5.25V
- Transducer Function: Current
- Weight: 30g
