OMRON - G7L-2A-T DC12 - Power Relay, DPST-NO, 12 VDC, 25 A, G7L, Panel Mount, Non Latching
- Contact Configuration: DPST-NO
 - Coil Voltage: 12VDC
 - Contact Current: 25A
 - Product Range: G7L Series
 - Relay Mounting: Panel
 - Coil Type: Non Latching
 - Contact Voltage VAC: 277VAC
 - Relay Terminals: Quick Connect
 - Contact Voltage VDC: -
 - Contact Material: Silver Alloy
 - Coil Resistance: 75ohm
 - Approvals & Standards: CSA, IEC, UL
 - Coil Current: 158mA
 - Coil Operating Lower Percent Limit: 75%
 - Coil Operating Upper Percent Limit: 110%
 - Coil Voltage VDC Nom: 12V
 - Contact Current AC Max: 25A
 - Contact Current Max: 25A
 - Contact Voltage AC Max: 220V
 - Contact Voltage AC Nom: 220V
 - DC Coil Power: 1.9W
 - External Depth: 47mm
 - External Height: 52.5mm
 - External Length / Height: 52.5mm
 - External Width: 33.5mm
 - Nom Operating Power: 1.9W
 - Operating Temperature Max: 60°C
 - Operating Temperature Min: -25°C
 - Relay Type: Power - General Purpose
