Description
OMRON - G6J-2FL-Y DC12 - Signal Relay, 12 VDC, DPDT, 1 A, G6J-Y, Surface Mount, Non Latching
- Coil Voltage: 12VDC
- Contact Configuration: DPDT
- Contact Current: 1A
- Product Range: G6J-Y Series
- Relay Mounting: SMD
- Coil Type: Non Latching
- Relay Terminals: Solder
- Contact Voltage VAC: -
- Contact Voltage VDC: 30V
- Contact Material: Silver Gold
- Coil Resistance: 976.8ohm
- Approvals & Standards: CSA, UL
- Coil Current: 12.3mA
- Coil Voltage VDC Nom: 12V
- Contact Current AC Max: 300mA
- Contact Current DC Max: 1A
- Contact Current Max: 1A
- Contact Voltage AC Max: 125V
- Contact Voltage AC Nom: 125V
- Contact Voltage DC Max: 110V
- Contact Voltage DC Nom: 110V
- External Depth: 5.7mm
- External Height: 10mm
- External Length / Height: 10mm
- External Width: 10.6mm
