OMRON - G4W2214PUSHP DC24 - General Purpose Relay, G4W Series, Power, Non Latching, DPST-NO, 24 VDC, 15 A
- Contact Configuration: DPST-NO
- Coil Voltage: 24VDC
- Contact Current: 15A
- Product Range: G4W Series
- Relay Mounting: Through Hole
- Coil Type: Non Latching
- Contact Voltage VAC: 250VAC
- Relay Terminals: Solder
- Contact Voltage VDC: 24VDC
- Contact Material: Silver Alloy
- Coil Resistance: 720ohm
- Coil Current: 33.3mA
- Coil Voltage VDC Nom: 24V
- Contact Current Max: 10A
- Contact Voltage AC Nom: 250V
- Contact Voltage DC Nom: 24V
- External Depth: 30.5mm
- External Height: 30.5mm
- External Width: 19.5mm
- Nom Operating Power: 800mW
- Relay Type: Power
