G2RG2A4 DC24 Relay, DPST-NO, 250VAC, 8A Omron

OMRONSKU: G2RG2A4 DC24 Order code: 2213726

Price:
Sale price€11,13

Tax included Shipping calculated at checkout

Stock:
In stock (19 units), ready to be shipped

Documents et téléchargements

Description

OMRON - G2RG2A4 DC24 - General Purpose Relay, G2R Series, Power, Non Latching, DPST-NO, 24 VDC, 8 A

  • Contact Configuration: DPST-NO
  • Coil Voltage: 24VDC
  • Contact Current: 8A
  • Product Range: G2R Series
  • Relay Mounting: Through Hole
  • Coil Type: Non Latching
  • Contact Voltage VAC: 250VAC
  • Relay Terminals: Solder
  • Contact Voltage VDC: -
  • Contact Material: Silver Alloy
  • Coil Resistance: 720ohm
  • Approvals & Standards: CSA, IEC, UL, VDE
  • Coil Current: 33.3mA
  • Coil Voltage VDC Nom: 24V
  • Contact Current Max: 8A
  • Contact Voltage AC Nom: 250V
  • Contact Voltage DC Nom: 125V
  • External Depth: 29mm
  • External Height: 25.5mm
  • External Width: 13.5mm
  • Nom Operating Power: 800mW
  • Relay Type: Power
