Description
PHOENIX CONTACT - FMCD 1,5/4-ST-3.5 - Pluggable Terminal Block, 3.5 mm, 4 Ways, 24AWG to 16AWG, 1.5 mm², Screw, 8 A
- Pitch Spacing: 3.5mm
- No. of Positions: 4Ways
- Wire Size (AWG): 24AWG to 16AWG
- Conductor Area CSA: 1.5mm²
- Wire Connection Method: Screw
- Rated Current: 8A
- Rated Voltage: 160V
- Product Range: Mini FMCD 1 Series
- SVHC: No SVHC (15-Jan-2018)
- Connector Mounting: PCB Mount
- Connector Type: Terminal Block, PCB
- Contact Material: Copper
- Contact Plating: Tin Plated Contacts
- Wire Size AWG Max: 16AWG
- Wire Size AWG Min: 24AWG
