WIMA - FKP2D012201D00JSSD - General Purpose Film Capacitor, Film / Foil PP, Radial Box - 2 Pin, 2200 pF, ± 5%, 63 V, 100 V
- Capacitance: 2200pF
 - Voltage Rating: 100V
 - Capacitor Dielectric Type: PP (Polypropylene)
 - Capacitance Tolerance: ± 5%
 - Product Range: FKP2 Series
 - Capacitor Case Style: -
 - Capacitor Terminals: Radial Leaded
 - Lead Spacing: 5mm
 - Operating Temperature Min: -55°C
 - Operating Temperature Max: 100°C
 - Automotive Qualification Standard: -
 - SVHC: No SVHC (15-Jan-2019)
 - Capacitance Tolerance ±: ± 5%
 - Capacitor Mounting: Through Hole
 - Climatic Category: 55/85/56
 - External Depth: 4.5mm
 - External Length / Height: 6mm
 - External Width: 7.2mm
 - Height: 6mm
 - Insulation Resistance: 50000Mohm
 - Lead Diameter: 0.5mm
 - Lead Length: 6mm
 - No. of Pins: 2Pins
 - Operating Temperature Range: -55°C to +85°C
 - Power Factor: 0.0004
 - Power Factor Frequency: 1kHz
 - Power Factor Temperature: 20°C
 - Resistance Insulation Temperature: 20°C
 - Temperature Coeff. -: -200ppm/°C
 - Temperature Coefficient: -200ppm/°C
 - Tolerance +: 5%
 - Tolerance -: 5%
 - Voltage Rating V DC: 100V
 - Voltage Rating VAC: 63V
