Description
WIMA - FKP1T003304B00KSSD - General Purpose Film Capacitor, Double Metallized PP, Radial Box - 2 Pin, 330 pF, ± 10%, 650 V
- Capacitance: 330pF
- Voltage Rating: 1.6kV
- Capacitor Dielectric Type: PP (Polypropylene)
- Capacitance Tolerance: ± 10%
- Product Range: FKP1 Series
- Capacitor Case Style: -
- Capacitor Terminals: Radial Leaded
- Lead Spacing: 15mm
- Operating Temperature Min: -55°C
- Operating Temperature Max: 100°C
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2019)
- Capacitance Tolerance ±: ± 10%
- Capacitor Mounting: Through Hole
- External Depth: 11mm
- External Length / Height: 18mm
- External Width: 5mm
- Height: 18mm
- No. of Pins: 2Pins
- Operating Temperature Range: -55°C to +100°C
- Voltage Rating V DC: 1.6kV
