ONSEMI - FDBL86063-F085 - Power MOSFET, N Channel, 100 V, 240 A, 0.002 ohm, H-PSOF, Surface Mount
- Transistor Polarity: N Channel
- Continuous Drain Current Id: 240A
- Drain Source Voltage Vds: 100V
- On Resistance Rds(on): 0.002ohm
- Rds(on) Test Voltage Vgs: 10V
- Threshold Voltage Vgs: 2.9V
- Power Dissipation Pd: 357W
- Transistor Case Style: H-PSOF
- No. of Pins: 8Pins
- Operating Temperature Max: 175°C
- Product Range: Trench Series
- Automotive Qualification Standard: AEC-Q101
- MSL: MSL 1 - Unlimited
- SVHC: No SVHC (15-Jan-2018)
