VISHAY - F339MX263031MYM2T0 - Safety Capacitor, Metallized PP, Radial Box - 2 Pin, 30 µF, ± 20%, X2, Through Hole
- Capacitance: 30µF
- Suppression Class: X2
- Product Range: F339M X2 Series
- Voltage Rating X: 310V
- Voltage Rating Y: -
- Capacitor Dielectric Type: PP (Polypropylene)
- Capacitance Tolerance: ± 20%
- dv/dt Rating: -
- Capacitor Case Style: -
- Capacitor Terminals: Radial Leaded
- Operating Temperature Min: -
- Operating Temperature Max: 110°C
- Automotive Qualification Standard: -
- SVHC: No SVHC (27-Jun-2018)
- Capacitor Application: Safety / Suppression
- External Depth: 30mm
- External Length / Height: 45mm
- External Width: 57.5mm
- Height: 45mm
- Lead Length: 5mm
- Lead Spacing: 52.5mm
- Voltage Rating VAC: 310V
