TE CONNECTIVITY - EP7W22RJ - Through Hole Resistor, 22 ohm, EP, 7 W, ± 5%, Axial Leaded, 500 V
- Resistance: 22ohm
- Product Range: EP Series
- Power Rating: 7W
- Resistance Tolerance: ± 5%
- Resistor Case Style: Axial Leaded
- Voltage Rating: 500V
- Resistor Element Material: Wirewound
- Temperature Coefficient: ± 400ppm/°C
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2019)
- Body Diameter: 8.5mm
- External Length / Height: 30mm
- Lead Diameter: 0.75mm
- Lead Length: 38mm
- Resistor Mounting: Through Hole
