PANASONIC - EEVTG1J101Q - SMD Aluminium Electrolytic Capacitor, Radial Can - SMD, 100 µF, 63 V, 0.26 ohm, 2000 hours @ 125°C
- AE Capacitor Case: Radial Can - SMD
- Capacitance: 100µF
- Voltage Rating: 63V
- ESR: 0.26ohm
- Product Range: TG Series
- Lifetime @ Temperature: 2000 hours @ 125°C
- Operating Temperature Min: -40°C
- Operating Temperature Max: 125°C
- Ripple Current AC: 350mA
- Diameter: 12.5mm
- Height: 13.5mm
- Automotive Qualification Standard: AEC-Q200
- MSL: -
- SVHC: No SVHC (15-Jan-2019)
- Capacitance Tolerance: ± 20%
- Capacitance Tolerance ±: ± 20%
- Capacitor Case Style: Radial Can - SMD
