Description
PANASONIC - EEVFK1C472M - SMD Aluminium Electrolytic Capacitor, Radial Can - SMD, 4700 µF, 16 V, 5000 hours @ 105°C, Polar
- AE Capacitor Case: Radial Can - SMD
- Capacitance: 4700µF
- Voltage Rating: 16V
- ESR: -
- Product Range: FK Series
- Lifetime @ Temperature: 5000 hours @ 105°C
- Operating Temperature Min: -55°C
- Operating Temperature Max: 105°C
- Ripple Current AC: 2.06A
- Diameter: 18mm
- Height: 16.5mm
- Automotive Qualification Standard: AEC-Q200
- MSL: MSL 1 - Unlimited
- SVHC: No SVHC (15-Jan-2019)
