Description
PANASONIC - EEUFR1J271 - Electrolytic Capacitor, Low ESR, 270 µF, 63 V, ± 20%, Radial Leaded, 10000 hours @ 105°C, Polar
- Capacitance: 270µF
- Voltage Rating: 63V
- Product Range: FR Series
- Capacitance Tolerance: ± 20%
- Capacitor Terminals: Radial Leaded
- Diameter: 12.5mm
- Lead Spacing: 5mm
- Height: 20mm
- Operating Temperature Min: -40°C
- Operating Temperature Max: 105°C
- Lifetime @ Temperature: 10000 hours @ 105°C
- ESR: 0.33ohm
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2019)
