EEUFR1A152L Cap, 1500µF, 10V, 20% Panasonic

PANASONICSKU: EEUFR1A152L Order code: 2760322

Price:
Sale price€1,30

Tax included Shipping calculated at checkout

Stock:
In stock (1307 units), ready to be shipped

Documents et téléchargements

Description

PANASONIC - EEUFR1A152L - Electrolytic Capacitor, 1500 µF, 10 V, ± 20%, Radial Leaded, 9000 hours @ 105°C, Polar

  • Capacitance: 1500µF
  • Voltage Rating: 10V
  • Product Range: FR Series
  • Capacitance Tolerance: ± 20%
  • Capacitor Terminals: Radial Leaded
  • Diameter: 8mm
  • Lead Spacing: 3.5mm
  • Height: 20mm
  • Operating Temperature Min: -40°C
  • Operating Temperature Max: 105°C
  • Lifetime @ Temperature: 9000 hours @ 105°C
  • ESR: -
  • Automotive Qualification Standard: -
  • SVHC: No SVHC (15-Jan-2019)
  • Capacitance Tolerance ±: ± 20%
  • Impedance: 0.03ohm
  • Impedance Frequency: 100kHz
  • Impedance Temperature: 20°C
  • Lead Diameter: 0.6mm
  • No. of Pins: 2Pins
  • Operating Temperature Range: -40°C to +105°C
  • Ripple Current AC: 1560mA
  • Ripple Current Frequency: 100kHz
  • Ripple Current Temperature: 105°C
