Description
PANASONIC - EEUFM1C471 - Electrolytic Capacitor, 470 µF, 16 V, ± 20%, Radial Leaded, 4000 hours @ 105°C, Polar
- Capacitance: 470µF
- Voltage Rating: 16V
- Product Range: FM Series
- Capacitance Tolerance: ± 20%
- Capacitor Terminals: Radial Leaded
- Diameter: 10mm
- Lead Spacing: 5mm
- Height: 15mm
- Operating Temperature Min: -40°C
- Operating Temperature Max: 105°C
- Lifetime @ Temperature: 4000 hours @ 105°C
- ESR: -
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2019)
- Capacitance Tolerance ±: ± 20%
- Impedance: 0.041ohm
- Lead Diameter: 0.6mm
- No. of Pins: 2Pins
- Operating Temperature Range: -40°C to +105°C
- Operating life Time: 3000h
- Ripple Current AC: 1240mA
