Description
PANASONIC - EEETG1J330P - SMD Aluminium Electrolytic Capacitor, Radial Can - SMD, 33 µF, 63 V, 0.8 ohm, 2000 hours @ 125°C
- AE Capacitor Case: Radial Can - SMD
- Capacitance: 33µF
- Voltage Rating: 63V
- ESR: 0.8ohm
- Product Range: TG Series
- Lifetime @ Temperature: 2000 hours @ 125°C
- Operating Temperature Min: -40°C
- Operating Temperature Max: 125°C
- Ripple Current AC: 150mA
- Diameter: 10mm
- Height: 10.2mm
- Automotive Qualification Standard: AEC-Q200
- MSL: -
- SVHC: No SVHC (15-Jan-2019)
