EEEFP1A331AP Cap, 330µF, 10V, Radial, SMD Panasonic

PANASONICSKU: EEEFP1A331AP Order code: 1539466

Price:
Sale price€1,85

Tax included Shipping calculated at checkout

Stock:
In stock (43 units), ready to be shipped

Documents et téléchargements

Description

PANASONIC - EEEFP1A331AP - SMD Aluminium Electrolytic Capacitor, Radial Can - SMD, 330 µF, 10 V, 0.08 ohm, 2000 hours @ 105°C

  • AE Capacitor Case: Radial Can - SMD
  • Capacitance: 330µF
  • Voltage Rating: 10V
  • ESR: 0.08ohm
  • Product Range: FP Series
  • Lifetime @ Temperature: 2000 hours @ 105°C
  • Operating Temperature Min: -55°C
  • Operating Temperature Max: 105°C
  • Ripple Current AC: 850mA
  • Diameter: 8mm
  • Height: 10.2mm
  • Automotive Qualification Standard: AEC-Q200
  • MSL: -
  • SVHC: No SVHC (15-Jan-2019)
  • Capacitance Tolerance: ± 20%
  • Capacitance Tolerance ±: ± 20%
  • Capacitor Case Style: Radial Can - SMD
  • External Length / Height: 10.2mm
  • Leakage Current: 33µA
  • Operating Temperature Range: -55°C to +105°C
