Description
PANASONIC - EEEFK1E102AQ - SMD Aluminium Electrolytic Capacitor, Radial Can - SMD, 1000 µF, 25 V, 5000 hours @ 105°C, Polar
- AE Capacitor Case: Radial Can - SMD
- Capacitance: 1000µF
- Voltage Rating: 25V
- ESR: -
- Product Range: AEC-Q200 FK Series
- Lifetime @ Temperature: 5000 hours @ 105°C
- Operating Temperature Min: -55°C
- Operating Temperature Max: 105°C
- Ripple Current AC: 1.1A
- Diameter: 12.5mm
- Height: 13.5mm
- Automotive Qualification Standard: -
- MSL: -
- SVHC: No SVHC (15-Jan-2019)
