Description
PANASONIC - EEEFC1A471P - SMD Aluminium Electrolytic Capacitor, Radial Can - SMD, 470 µF, 10 V, 1000 hours @ 105°C, Polar
- AE Capacitor Case: Radial Can - SMD
- Capacitance: 470µF
- Voltage Rating: 10V
- ESR: -
- Product Range: FC Series
- Lifetime @ Temperature: 1000 hours @ 105°C
- Operating Temperature Min: -40°C
- Operating Temperature Max: 105°C
- Ripple Current AC: 670mA
- Diameter: 10mm
- Height: 10.2mm
- Automotive Qualification Standard: AEC-Q200
- MSL: MSL 1 - Unlimited
- SVHC: No SVHC (15-Jan-2019)
