EA ELEKTRO-AUTOMATIK - EA-PS 812-12-80 DOUBLE - Bench Power Supply, Adjustable, 2 Output, 11.8 V, 15.2 V, 2.5 A, 6.7 A
- Power Supply Output Type: Adjustable
- No. of Outputs: 2 Output
- Output Voltage Min: 11.8V
- Output Voltage Max: 15.2V
- Output Current Min: 2.5A
- Output Current Max: 6.7A
- Power Rating: 80W
- Supply Voltage Min: 90VAC
- Supply Voltage Max: 264VAC
- Manufacturer Warranty: 2 Years
- Product Range: EA-PS 800 Series
- Plug Type: -
- SVHC: No SVHC (15-Jan-2019)
- Approval Bodies: CE, EN, IEC
- Efficiency: 89%
- External Depth: 162mm
- External Length / Height: 162mm
- External Width: 40.64mm
- Height: 133.35mm
- Input Voltage: 90V AC to 264V AC
- Input Voltage DC Max: 360VDC
- Input Voltage DC Min: 90VDC
- Length: 162mm
- Load Current Max: 8A
- Load Regulation: 0.2%
- No. of Outputs: 2Outputs
- Operating Temperature Max: 70°C
- Operating Temperature Min: 0°C
- Output Current: 7.5A
- Output Current - Output 2: 2.5A
- Output Power Max: 80W
- Output Voltage: 12V
- Output Voltage - Output 2: 12V
- Power Supply Type: Switch Mode
- Storage Temperature Min: -40°C
- Supply Frequency Max: 65Hz
- Supply Frequency Min: 45Hz
- Supply Voltage: 240V
