Description
HIROSE(HRS) - DF11-6DP-2DS(24) - Pin Header, Right Angle, Wire-to-Board, 2 mm, 2 Rows, 6 Contacts, Through Hole Right Angle
- Pitch Spacing: 2mm
- No. of Contacts: 6Contacts
- Gender: Header
- Product Range: -
- Contact Termination Type: Through Hole
- No. of Rows: 2Rows
- Contact Plating: Tin Plated Contacts
- Contact Material: Brass
- SVHC: No SVHC (15-Jan-2019)
- Colour: Black
- Contact Resistance: 30mohm
- Flammability Rating: UL94V-0
- Insulation Resistance: 1000Mohm
- No. of Mating Cycles: 30
- Row Pitch: 2mm
- Voltage Rating VAC: 30V
