Description
OMRON - D2FD-01L1-1H - Microswitch, Ultra Subminiature, Hinge Lever, SPDT, Solder, 100 mA, 30 VDC
- Microswitch Type: Ultra Subminiature
- Microswitch Actuator: Hinge Lever
- Contact Configuration: SPDT
- Switch Terminals: Solder
- Contact Current Max: 100mA
- Contact Voltage DC Nom: 30VDC
- Product Range: -
- Contact Voltage AC Nom: 125VAC
- Operating Force Max: 0.65N
- Contact Resistance: 100mohm
- No. of Electrical Operations: 100000
- No. of Mechanical Operations: 300000
- Operating Temperature Max: 70°C
- Operating Temperature Min: -20°C
