CTB9208/8 Terminal Block, Pluggable, 8Pos, 12AWG Camdenboss

CAMDENBOSSSKU: CTB9208/8 Order code: 2334954

Price:
Sale price€15,84

Tax included Shipping calculated at checkout

Stock:
In stock (5 units), ready to be shipped

Documents et téléchargements

Description

CAMDENBOSS - CTB9208/8 - Pluggable Terminal Block, 5.08 mm, 8 Ways, 30AWG to 12AWG, Screw, 12 A

  • Pitch Spacing: 5.08mm
  • No. of Positions: 8Ways
  • Wire Size (AWG): 30AWG to 12AWG
  • Conductor Area CSA: -
  • Wire Connection Method: Screw
  • Rated Current: 12A
  • Rated Voltage: 300V
  • Product Range: CTB9208 Series
  • SVHC: No SVHC (15-Jan-2019)
  • Cable Diameter Max: 2.50mm
  • Colour: Green
  • Connector Mounting: Cable Mount
  • Connector Type: Terminal Block, Pluggable
  • Contact Material: Brass
  • Contact Plating: Tin Plated Contacts
  • Current Rating: 12A
  • Insulation Resistance: 5Mohm
  • Length: 40.64mm
  • Material: UL94-V0 Flame Retardant PA66
  • No. of Contacts: 8Contacts
  • Operating Temperature Max: 125°C
  • Operating Temperature Min: -20°C
  • Wire Size AWG Max: 12AWG
  • Wire Size AWG Min: 30AWG
  • Wire Size Range (AWG): 10
  • Withstand Voltage: 2.5kV
  • Working Voltage: 380V
