CAMDENBOSS - CTB77VP/3 - Standard Terminal Block, Wire to Board, CTB77VP, 3 Contacts, 10.16 mm, Terminal Block, PCB
- Product Range: CTB77VP Series
- No. of Contacts: 3Contacts
- Pitch Spacing: 10.16mm
- Connector Type: Terminal Block, PCB
- Connector Mounting: PCB Mount
- Wire Size AWG Max: 6AWG
- Wire Size AWG Min: -
- Contact Plating: Tin Plated Contacts
- Contact Material: Brass
- SVHC: No SVHC (15-Jan-2019)
- Approval Bodies: UL
- Approval Category: IMQ, VDE
- Block Orientation: Through Hole Right Angle
- Conductor Area CSA: 10mm²
- Current Rating: 57A
- External Length / Height: 30.48mm
- Flammability Rating: UL94V-0
- Height: 30.48mm
- Insulation Resistance: 5Mohm
- No. of Positions: 3Ways
- Operating Temperature Max: 110°C
- Operating Temperature Min: -20°C
- Rated Current: 40A
- Rated Voltage: 300V
- Voltage Rating VAC: 750V
- Wire Connection Method: Screw
- Wire Size (AWG): 20AWG to 6AWG
- Wire Size Range (AWG): 6
