SENSATA/CRYDOM - CMX200D3 - Solid State Relay, CMX Series, DIP, DC Output, SPST-NO, 3 A, 200 VDC, PCB, Through Hole, DC Switch
- Contact Configuration: SPST-NO
- Load Current: 3A
- Operating Voltage Max: 200VDC
- Relay Mounting: PCB
- Relay Terminals: Through Hole
- Switching Mode: DC Switch
- Operating Voltage Min: 0VDC
- Control Voltage Min: 3VDC
- Control Voltage Max: 10VDC
- Product Range: CMX Series
- SVHC: No SVHC (12-Jan-2017)
- Control Voltage DC Max: 10VDC
- Control Voltage DC Min: 3VDC
- Control Voltage Range: 3V DC to 10V DC
- Control Voltage Type: DC
- Forward Current If: 15mA
- Input Current: 15mA
- Input Voltage: 3V DC to 10V DC
- Isolation Voltage: 2.5kV
- Load Current Min: 0mA
- Load Voltage Max: 200VDC
- Load Voltage Range: 0V DC to 200V DC
- On State Resistance Max: 0.2ohm
- Output Type: MOSFET
