Description
PHOENIX CONTACT - 2885249 - MONITORING RELAY, EMD-FL-3V-690
- Load Current Inductive: 10A
- Relay Mounting: DIN Rail
- Operating Voltage: 600VAC
- Contact Configuration: 2NO / 2NC
- No. of Poles: 4 Pole
- Switching Power AC3: -
- Switching Current AC1: -
- Coil Voltage VAC Nom: 240V
- Coil Voltage VDC Nom: -
- Switching Power AC1: -
- Load Current Resistive: 10A
- Switching Current AC3: -
- Product Range: TeSys CAK Series
- SVHC: No SVHC (15-Jan-2018)
- AC Coil Power: 4.5VA
- Coil Operating Lower Percent Limit: 70%
- Coil Operating Upper Percent Limit: 130%
- Coil Type: AC
- Contact Current AC Max: 10A
- Contact Voltage AC Max: 690V
- DC Coil Power: 1.5W
- External Depth: 57mm
- External Length / Height: 58mm
- External Width: 45mm
- Main Contact Current AC1 Max: 10A
- Nom Operating Power: 4.5VA
- Relay Type: Contactor
