Description
CREE LED - C503B-GAS-CBOF0791 - LED, Green, Through Hole, T-1 3/4 (5mm), 20 mA, 3.2 V, 535 nm
- LED Colour: Green
 - LED Mounting: Through Hole
 - LED Case Size: T-1 3/4 (5mm)
 - Forward Current If: 20mA
 - Forward Voltage: 3.2V
 - Wavelength Typ: 535nm
 - Luminous Intensity: 34cd
 - Viewing Angle: 15°
 - Lens Shape: Round
 - Product Range: -
 - Automotive Qualification Standard: -
 - MSL: -
 - Bulb Size: T-1 3/4 (5mm)
 - Dominant Wavelength: 527nm
 - Forward Current If Max: 20mA
 - Forward Voltage VF Max: 4V
 - LED / Lamp Size: 5mm / T-1 3/4
 - LED Type: Standard
 - Lead Diameter: 0.5mm
 - Lead Length: 25mm
 - Lead Spacing: 2.54mm
 - Lens Diameter: 5mm
 - Lens Length: 8.8mm
 - Luminous Intensity Typ: 34000mcd
 - No. of Pins: 2Pins
 - Operating Temperature Max: 95°C
 - Operating Temperature Min: -40°C
 - Operating Temperature Range: -40°C to +95°C
