Description
VISHAY - BFC233820334 - Safety Capacitor, Metallized PP, Radial Box - 2 Pin, 0.33 µF, ± 20%, X2, Through Hole
- Capacitance: 0.33µF
- Suppression Class: X2
- Product Range: MKP3382 X2 Series
- Voltage Rating X: 310V
- Voltage Rating Y: -
- Capacitor Dielectric Type: PP (Polypropylene)
- Capacitance Tolerance: ± 20%
- dv/dt Rating: -
- Capacitor Case Style: -
- Capacitor Terminals: Radial Leaded
- Operating Temperature Min: -55°C
- Operating Temperature Max: 105°C
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2019)
- Approval Bodies: CSA, D, FI, IMQ, N, OVE, S, SEV, UL, VDE
- Capacitor Application: Safety / Suppression
- External Depth: 10mm
- External Length / Height: 16.5mm
- External Width: 17.5mm
- Height: 16.5mm
- Lead Diameter: 0.8mm
- Lead Spacing: 15mm
- Operating Temperature Range: -55°C to +105°C
- Pulse Rise Time: 100µs
- Voltage Rating VAC: 440V
