EPCOS - B72240L0131K100 - TVS Varistor, 130 V, 170 V, B722 HighE Standard LS40, 340 V, Disc 40mm
- Voltage Rating VAC: 130V
- Voltage Rating V DC: 170V
- Product Range: B722 HighE Standard LS40 Series
- Clamping Voltage Vc Max: 340V
- Varistor Case Style: Disc 40mm
- Varistor Type: Metal Oxide Varistor (MOV)
- Peak Surge Current @ 8/20µs: 40kA
- Operating Temperature Min: -25°C
- Operating Temperature Max: 85°C
- Peak Energy (10/1000uS): 310J
- Automotive Qualification Standard: -
- SVHC: No SVHC (27-Jun-2018)
