Description
KEMET - ALS40A333MF063 - Electrolytic Capacitor, 33000 µF, 63 V, ± 20%, Screw, 13000 hours @ 105°C
- Capacitance: 33000µF
- Voltage Rating: 63V
- Product Range: ALS40 Series
- Lifetime @ Temperature: 13000 hours @ 105°C
- Capacitance Tolerance: ± 20%
- Capacitor Terminals: Screw
- Diameter: 66mm
- Lead Spacing: 28.5mm
- Operating Temperature Min: -40°C
- Operating Temperature Max: 105°C
- Height: 105mm
- ESR: 0.008ohm
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2018)
- AC Ripple Current @ 100Hz: 21.3A
- AC Ripple Current @ 10kHz: 22.2A
- Capacitance Tolerance ±: ± 20%
- Climatic Category: 40/085/56
- ESR Frequency: 100Hz
- ESR Temperature: 20°C
- External Length / Height: 105mm
- Operating Life Temperature: 105°C
- Operating Temperature Range: -40°C to +105°C
- Operating life Time: 13000h
- Ripple Current AC: 21.3A
- Ripple Current Frequency: 100Hz
- Ripple Current Temperature: 105°C
