Description
KEMET - ALC10C153EF063 - Electrolytic Capacitor, Long Life, 15000 µF, 63 V, ± 20%, Snap-In, 18000 hours @ 85°C
- Capacitance: 15000µF
- Voltage Rating: 63V
- Product Range: ALC10 Series
- Lifetime @ Temperature: 18000 hours @ 85°C
- Capacitance Tolerance: ± 20%
- Capacitor Terminals: Quick Connect, Snap-In
- Diameter: 40mm
- Lead Spacing: 22.5mm
- Operating Temperature Min: -40°C
- Operating Temperature Max: 85°C
- Height: 50mm
- ESR: 0.044ohm
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2018)
- AC Ripple Current @ 10kHz: 7.18A
- Capacitance Tolerance ±: ± 20%
- ESR Frequency: 100Hz
- ESR Temperature: 20°C
- External Length / Height: 50mm
- Leakage Current: 5674µA
- No. of Pins: 4Pins
- Operating Life Temperature: 85°C
- Operating Temperature Range: -40°C to +85°C
- Operating life Time: 18000h
- Ripple Current AC: 7.02A
- Ripple Current Frequency: 85Hz
- Ripple Current Temperature: 85°C
- Tolerance +: 20%
- Tolerance -: 20%
- Voltage Rating V DC: 63V
