Description
WURTH ELEKTRONIK - 744052005 - Power Inductor (SMD), 5 µH, 1.65 A, Shielded, 1.8 A, WE-TPC
- Inductance: 5µH
- RMS Current (Irms): 1.65A
- Inductor Construction: Shielded
- Saturation Current (Isat): 1.8A
- Product Range: WE-TPC Series
- Power Inductor Case: 5.8mm x 5.8mm x 1.8mm
- DC Resistance Max: 0.06ohm
- Inductance Tolerance: ± 30%
- SVHC: No SVHC (15-Jan-2019)
- Inductor Type: Power
- No. of Pins: 2Pins
- Resonant Frequency: 55MHz
- Self Resonant Frequency Min: 55MHz
