Description
WAGO - 733-104. - Pluggable Terminal Block, 2.5 mm, 4 Ways, 28AWG to 20AWG, 0.5 mm², Clamp, 6 A
- Pitch Spacing: 2.5mm
- No. of Positions: 4Ways
- Wire Size (AWG): 28AWG to 20AWG
- Conductor Area CSA: 0.5mm²
- Wire Connection Method: Clamp
- Rated Current: 6A
- Rated Voltage: 160V
- Product Range: 733 Series
- SVHC: No SVHC (15-Jan-2018)
- Connector Mounting: PCB Mount
- Connector Type: Terminal Block
- Contact Material: Copper
- Contact Plating: Tin Plated Contacts
- Wire Size AWG Max: 20AWG
- Wire Size AWG Min: 28AWG
