Description
WURTH ELEKTRONIK - 691709710303 - Wire-To-Board Terminal Block, 5 mm, 3 Ways, 30 AWG, 14 AWG, 2 mm², Screw
- Pitch Spacing: 5mm
- No. of Positions: 3Ways
- Wire Size AWG Min: 30AWG
- Wire Size AWG Max: 14AWG
- Conductor Area CSA: 2mm²
- Wire Connection Method: Screw
- Rated Current: 6A
- Rated Voltage: 300V
- Block Orientation: Surface Mount Right Angle
- Product Range: 7097 Series
- SVHC: Lead (15-Jan-2019)
- Connector Mounting: PCB Mount
- Connector Type: Terminal Block, PCB
- Contact Plating: Tin Plated Contacts
