RUBYCON - 50ZLJ680M12.5X25 - Electrolytic Capacitor, Miniature, 680 µF, 50 V, ± 20%, Radial Leaded, 10000 hours @ 105°C, Polar
- Capacitance: 680µF
- Voltage Rating: 50V
- Product Range: ZLJ Series
- Capacitance Tolerance: ± 20%
- Capacitor Terminals: Radial Leaded
- Diameter: 12.5mm
- Lead Spacing: 5mm
- Height: 25mm
- Operating Temperature Min: -40°C
- Operating Temperature Max: 105°C
- Lifetime @ Temperature: 10000 hours @ 105°C
- ESR: -
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2018)
- Capacitance Tolerance ±: ± 20%
- Ripple Current AC: 2800mA
