Description
ISOCOM - 4N25X - Optocoupler, Transistor Output, 1 Channel, DIP, 6 Pins, 60 mA, 5.3 kV, 20 %
- No. of Channels: 1 Channel
- Optocoupler Case Style: DIP
- No. of Pins: 6Pins
- Forward Current If Max: 60mA
- Isolation Voltage: 5.3kV
- CTR Min: 20%
- Collector Emitter Voltage V(br)ceo: 30V
- Product Range: 4N25X, 4N26X, 4N27X, 4N28X, 4N25, 4N26, 4N27, 4N28
- SVHC: No SVHC (15-Jan-2019)
- Input Current: 10mA
- No. of Channels: 1Channels
- Operating Temperature Max: 100°C
- Operating Temperature Min: -55°C
- Operating Temperature Range: -55°C to +100°C
- Optocoupler Output Type: Phototransistor
- Output Voltage: 30V
