FINDER - 34.51.7.048.0010 - General Purpose Relay, 34 Series, SPDT, 48 VDC, 6 A
- Contact Configuration: SPDT
- Coil Voltage: 48VDC
- Contact Current: 6A
- Product Range: 34 Series
- Relay Mounting: Through Hole
- Coil Type: -
- Contact Voltage VAC: 250VAC
- Relay Terminals: Solder
- Contact Voltage VDC: -
- Contact Material: Silver Nickel
- Coil Resistance: 12.3kohm
- SVHC: No SVHC (15-Jan-2019)
- Coil Current: 3.9mA
- Coil Voltage VDC Nom: 48V
- Contact Current AC Max: 6A
- Contact Current Max: 10A
- Contact Current Rating: 6A
- Contact Voltage AC Max: 400V
- Contact Voltage AC Nom: 250V
- DC Coil Power: 0.17W
- External Depth: 5mm
- External Height: 15mm
- External Length / Height: 15mm
- External Width: 28mm
- No. of Mechanical Operations: 10000000
- Nom Operating Power: 170mW
- Operating Temperature Max: 85°C
- Operating Temperature Min: -40°C
- Power Rating: 1.5kVA
- Relay Type: General Purpose
- Switching Voltage AC / DC Min: 250VAC
