Description
BEHA-AMPROBE - 33XR-A - Manual Ranging Digital Multimeter, 3999 Count, True RMS, Auto, Manual Range, 3.75 Digit
- DMM Functions: Current, Voltage, Capacitance, Frequency, Resistance, Temperature
 - Current Measure AC Max: 10A
 - Current Measure DC Max: 10A
 - Voltage Measure AC Max: 750V
 - Voltage Measure DC Max: 1kV
 - Resistance Measure Max: 4Mohm
 - DMM Response Type: True RMS
 - Display Count: 3999
 - No. of Digits: 3.75
 - Range Selection: Auto, Manual
 - Manufacturer Warranty: 1 Year
 - Product Range: -
 - SVHC: No SVHC (15-Jun-2015)
 - Approval Bodies: IEC
 - Battery Lifetime: 200h
 - Capacitance Max: 4mF
 - Capacitance Measuring Range: 4µF to 4mF
 - Current Max: 10A
 - Current Measuring Range AC: 400µA to 10A
 - Current Measuring Range DC: 400µA to 10A
 - Current Range AC: 400µA to 10A
 - Current Range DC: 400µA to 10A
 - DMM Type: Hand Held
 - External Depth: 60mm
 - External Length / Height: 196mm
 - External Width: 92mm
 - Ranging: Auto, Manual
 - Resistance: 4Mohm
 - Temperature Measuring Range: -20°C to +1000°C
 - Voltage Measuring Range AC: 400mV to 750V
 - Voltage Measuring Range DC: 400mV to 1kV
 - Voltage Rating V DC: 1000V
 - Voltage Rating VAC: 750V
