CORNELL DUBILIER - 3186FE332M400MPC1 - Electrolytic Capacitor, Screw, 3300 µF, 400 V, ± 20%, Screw, 2000 hours @ 85°C
- Capacitance: 3300µF
- Voltage Rating: 400V
- Product Range: 3186 Series
- Lifetime @ Temperature: 2000 hours @ 85°C
- Capacitance Tolerance: ± 20%
- Capacitor Terminals: Screw
- Diameter: 63.5mm
- Lead Spacing: 28.6mm
- Operating Temperature Min: -40°C
- Operating Temperature Max: 85°C
- Height: 105mm
- ESR: -
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2018)
- Capacitance Tolerance ±: ± 20%
- No. of Pins: 2Pins
- Operating Temperature Range: -40°C to +85°C
