Description
METZ CONNECT - 31086105 - Wire-To-Board Terminal Block, 3.81 mm, 5 Ways, 28 AWG, 16 AWG, 1.5 mm², Screw
- Pitch Spacing: 3.81mm
- No. of Positions: 5Ways
- Wire Size AWG Min: 28AWG
- Wire Size AWG Max: 16AWG
- Conductor Area CSA: 1.5mm²
- Wire Connection Method: Screw
- Rated Current: 10A
- Rated Voltage: 150V
- Block Orientation: Through Hole Right Angle
- Product Range: -
- SVHC: No SVHC (07-Jul-2017)
