Description
WEIDMULLER - 1884540000 - Standard Terminal Block, 3 Contacts, 5 mm, Terminal Block, PCB, PCB Mount, 16 AWG
- Product Range: -
- No. of Contacts: 3Contacts
- Pitch Spacing: 5mm
- Connector Type: Terminal Block, PCB
- Connector Mounting: PCB Mount
- Wire Size AWG Max: 16AWG
- Wire Size AWG Min: 24AWG
- Contact Plating: Tin Plated Contacts
- Contact Material: Copper
- SVHC: No SVHC (15-Jan-2018)
- Colour: Black
- Flammability Rating: UL94V-0
- Voltage Rating VAC: 500V
- Wire Area Size Max: 1.5mm²
- Wire Area Size Min: 0.25mm²
