Description
RUBYCON - 16TZV470M8X10.5 - SMD Aluminium Electrolytic Capacitor, Radial Can - SMD, 470 µF, 16 V, 2000 hours @ 105°C, Polar
- AE Capacitor Case: Radial Can - SMD
 - Capacitance: 470µF
 - Voltage Rating: 16V
 - ESR: -
 - Product Range: TZV Series
 - Lifetime @ Temperature: 2000 hours @ 105°C
 - Operating Temperature Min: -55°C
 - Operating Temperature Max: 105°C
 - Ripple Current AC: 600mA
 - Diameter: 8mm
 - Height: 10.5mm
 - Automotive Qualification Standard: -
 - MSL: -
 - SVHC: No SVHC (15-Jan-2018)
 - Capacitance Tolerance: ± 20%
 - Capacitance Tolerance ±: ± 20%
 - Capacitor Case Style: Radial Can - SMD
 - External Length / Height: 10.5mm
 - Frequency Tolerance: 120Hz
 - Impedance: 0.16ohm
 - Impedance Frequency: 100kHz
 - Impedance Temperature: 20°C
 - Operating Temperature Range: -55°C to +105°C
 - Operating life Time: 2000h
 - Ripple Current Frequency: 100kHz
 - Ripple Current Temperature: 105°C
 - Tolerance +: 20%
 - Tolerance -: 20%
 - Tolerance Temperature: 20°C
 - Voltage Rating V DC: 16V
 - Voltage Rating VAC: 16V
