Description
RUBYCON - 160BXW270MEFR16X25 - Electrolytic Capacitor, Miniature, 270 µF, 160 V, ± 20%, Radial Leaded, 12000 hours @ 105°C, Polar
- Capacitance: 270µF
- Voltage Rating: 160V
- Product Range: BXW Series
- Capacitance Tolerance: ± 20%
- Capacitor Terminals: Radial Leaded
- Diameter: 16mm
- Lead Spacing: 7.5mm
- Height: 25mm
- Operating Temperature Min: -40°C
- Operating Temperature Max: 105°C
- Lifetime @ Temperature: 12000 hours @ 105°C
- ESR: -
- Automotive Qualification Standard: -
- SVHC: No SVHC (15-Jan-2018)
