CGS - TE CONNECTIVITY - YP1047KJ - Resistor, 47 kohm, YP, 10 W, ± 5%, 825 V
- Resistance: 47kohm
- Product Range: YP Series
- Power Rating: 10W
- Resistance Tolerance: ± 5%
- Resistor Terminals: -
- Voltage Rating: 825V
- Resistor Element Material: Wirewound
- Temperature Coefficient: ± 100ppm/°C
- Body Diameter: 9.5mm
- External Depth: 21mm
- External Length / Height: 50mm
- External Width: 15mm
- Operating Temperature Max: 105°C
- Operating Temperature Min: -55°C
- Operating Temperature Range: -55°C to +105°C
- Resistor Mounting: Panel
- Temperature Coeff. +: 100ppm/°C
- Temperature Coeff. -: 100ppm/°C
- Tolerance +: 5%
- Tolerance -: 5%
- Voltage Rating V DC: 825V
- Voltage Rating VAC: 825V
