TDK - VLS6045EX-R47N - Power Inductor (SMD), Wirewound, 470 nH, 7 A, Shielded, 13.5 A, VLS-EX
- Inductance: 470nH
- RMS Current (Irms): 7A
- Inductor Construction: Wirewound
- Saturation Current (Isat): 13.5A
- Product Range: VLS-EX Series
- Power Inductor Case: 6mm x 6mm x 4.5mm
- DC Resistance Max: 0.01ohm
- Inductance Tolerance: ± 30%
- SVHC: No SVHC (15-Jan-2019)
